With sine-wave drive (PMSM), current THD can be less than 5%, and the amplitude of frame vibration is typically less than 0.5 mm/s.
The carrier frequency can be increased to the ultrasonic range of over 20 kHz, beyond the range of human hearing, enabling virtually “silent” operation.
FOC sine-wave drive ensures continuous rotation of the stator magnetic field, resulting in motor operation that is as smooth as silk compared to square-wave drive.
Model | Voltage(V) | No Load | Rated Load | Stall | ||||||
Operating Range | Rated | Speed (rpm) | Current (A) | Torque (mNm) | Speed (rpm) | Current (A) | Output P. (W) | Torque (mNm) | Current (A) | |
LHBL3040-01 | 5-12 | 6 | 1992 | 0.14 | 15 | 1464 | 0.71 | 2.30 | 56.54 | 0.9 |
LHBL3040-02 | 8-26 | 12 | 3698 | 0.10 | 10 | 3165 | 0.44 | 3.32 | 69.43 | 2.8 |
LHBL3040-03 | 8-26 | 12 | 3986 | 0.14 | 30 | 2830 | 1.24 | 8.89 | 103.4 | 2.8 |
LHBL3040-04 | 8-26 | 24 | 3615 | 0.06 | 10 | 3139 | 0.23 | 3.29 | 76.02 | 2.4 |
LHBL3040-05 | 8-26 | 24 | 5475 | 0.09 | 30 | 4384 | 0.84 | 13.77 | 150.6 | 2.4 |
Medical Devices
Fluid pumps, infusion pumps, respiratory equipment
Smart Home Appliances
Robot vacuum cleaners, smart lawn mowers, rotating serving platters
Personal Care
Beauty devices, hair dryers, electric hair clippers
Industrial Equipment
Vending machines, small mixers, conveyor rollers, mixers
1. Q: Do standard brushless DC motors offer water and dust resistance?
A: Standard brushless motors only have IP20 protection and are not waterproof. Customized IP54/IP65 sealed models are available, featuring rubber gaskets and anti-corrosion coatings, making them suitable for humid, dusty, or environments with light water splashes.
2. Q: What applications are small-diameter micro brushless motors suitable for?
A: Micro brushless motors are suitable for products with limited installation space and low power requirements, such as personal care tools, medical rehabilitation massagers, rechargeable screwdrivers, mini beauty devices, and small smart fans.
3. Q: What mounting options are available for brushless motors?
A: Standard mounting options include front flange mounting, rear foot mounting, and shaft-end mounting. We can customize mounting holes, locating tabs, and mounting plate designs to match the installation dimensions of the customer's equipment.
