24
Lower energy consumption during long-term continuous operation effectively reduces equipment electricity costs.
Supports both Hall-effect sensor and sensorless control schemes, and is compatible with various speed control communication protocols, including PWM, 0–10 V analog signals, and CAN bus.
High-precision dynamic balancing of the rotor ensures vibration-free operation at high speeds and prevents deformation during long-term operation
Model | Voltage(V) | No Load | Rated Load | Stall | ||||||
Operating Range | Rated | Speed (rpm) | Current (A) | Torque (mNm) | Speed (rpm) | Current (A) | Output P. (W) | Torque (mNm) | Current (A) | |
LHBL2430-01 | 5-12 | 6 | 5380 | 0.23 | 3.92 | 4720 | 0.61 | 1.94 | 13.2 | 1.5 |
LHBL2430-02 | 5-12 | 9 | 5390 | 0.11 | 9.81 | 3750 | 0.71 | 3.85 | 23.2 | 1.5 |
LHBL2430-03 | 8-26 | 12 | 8800 | 0.155 | 9.81 | 6330 | 0.85 | 6.51 | 35.16 | 2.66 |
LHBL2430-04 | 8-26 | 24 | 4570 | 0.05 | 6.87 | 3510 | 0.18 | 2.53 | 29.59 | 0.64 |
Medical Devices
Diaphragm pumps, infusion pumps, insulin pumps, syringe pumps, vacuum pumps
Smart Home Appliances
Rotating dinner plates, aromatherapy diffusers, coffee makers, humidifiers
Personal Care
Curling irons, hair dryers, electric hair clippers, waist and abdominal massagers, mini foam rollers
Industrial Equipment
Projectors, paper shredders, ATMs, automatic doors
1. Q: What is the difference between a brushless DC (BLDC) motor and a brushed DC motor?
A: A brushless DC motor eliminates the carbon brush mechanism and relies on Hall sensors or sensorless algorithms for electronic commutation, paired with a permanent magnet rotor. Compared to brushed DC motors, it offers higher energy efficiency, a longer service life, and quieter operation, making it suitable for driving precision industrial and consumer equipment.
2. Q: What are the key advantages of brushless DC motors over brushed DC motors?
A: Brushless motors eliminate carbon brush wear and electrical spark interference, achieving energy efficiency of 85%–95%. They operate with minimal vibration and lower noise, support long periods of continuous operation, significantly reduce maintenance costs, and are suitable for equipment with stringent stability requirements, such as medical devices, smart home systems, and automotive applications.
3. Q: What is the maximum speed range for micro brushless motors?
A: The rated speed range for micro brushless motors is 1,000 rpm to 30,000 rpm. Ultra-high-speed models undergo dynamic balancing and are equipped with high-speed bearings to eliminate rotor vibration at high speeds.
